ProStar 430 Autosampler Control Manual - 31 - 03-914947-33:2
Running Acquisition Status
Viewing a Running Acquisition
To view a running acquisition, click on the Systems tab then
select the running system. A window is activated which is
composed of two parts: the running chromatogram and the
status window where the driver modules are listed.
Varian ProStar 430 AutoSampler Status
Click on the button corresponding to the ProStar 430
driver and the autosampler status screen will appear. It contains
up to five sub-sections depending of the installed options:
Status, Remote control, Plate cooling, Plate feeder and
Overview. Click on the required sub-section to display the
corresponding parameters that will be used during the
chromatographic run.
A toolbar enables to easily scroll through the status windows:
to select the first status window.
to move back to the previous status window.
to move forward to the next status window.
to select the final status window.
