ProStar 430 Autosampler Control Manual - 32 - 03-914947-33:2
Status Window
State parameter group:
The upper field indicates the autosampler status.
The led of the Device detection field indicates the
communication state with the instrument : the led is green when
there is communication.
The ROM version field gives the ROM version of the
autosampler.
During acquisition, the injected well and volume are also
displayed.
Auxiliaries parameter group:
Green lights indicate if the corresponding relay is activated or
not.
Each relay can be opened or closed by clicking on the
button.
Options parameter group:
Solvent switch indicates the solvent stream which is used at the
specified time.
