Top Lid ..............................................................AR81-21 ..................................................AR101-21
Screw for Lid M6x20 ......................................... STA5017 ..................................................STA5017
Threaded Bushing ............................................STA6580 ..................................................STA6580
Ground Screw...................................................STA5232 ..................................................STA5232
Arrow Label ......................................................R15-245 ...................................................R15-245
Plug Button .......................................................STA6525 ..................................................STA6525
Bushings for Bowl Arm Shaft ............................STA2526 ..................................................STA2526
Knee Pad .......................................................... AR80-212 ................................................AR80-212
Foot ..................................................................AR80-213 ................................................AR80-213
3MM Foot .........................................................AR80-214.3 .............................................AR80-214.3
6MM Foot .........................................................AR80-214.6 .............................................AR80-214.6
Screw M6X10 ...................................................STA5080 ..................................................STA5080
Rear Panel........................................................AR81-22.17R ...........................................AR101-22.17R
Upper NSF Plate ..............................................AR81-270 ................................................AR81-270
Lock Nut ...........................................................STA5834 ..................................................STA5834
Washer .............................................................STA6027 ..................................................STA6027
Lower NSF Plate ..............................................AR81-271 ................................................AR81-271
Plug Button f/ No Hub ....................................... STA6510 ..................................................N/A
Machine Column................................................................................................................
Motor mount .....................................................AR81-148.1 .............................................AR81-148.1
Bolt ...................................................................STA5686 ..................................................STA5686
Washer .............................................................STA6056 ..................................................STA6056
Bushings for Bowl Lift Lever .............................STA2515 ..................................................N/A
Bowl Arm Guide Plade......................................AR81-71 ..................................................AR81-71
Screw................................................................STA5322 ..................................................STA5322
spring washer ...................................................STA6056 ..................................................STA6056
Washer .............................................................STA6020 ..................................................STA6020
Nut ....................................................................STA5810 ..................................................STA5810
Threaded Bush .................................................R20-148 ...................................................R20-148
Nut ....................................................................STA5815 ..................................................STA5815
Fig.

2.
3.
4.
5.
6.
7.
8.
9.










20.

22.
23.
24.
25.
26.
27.
28.
29.
30.

  
