Varimixer V80 - Transmission

25
Fig.

2.
3.
4.
5.
6.
7.
8.
9.









20.

22.
23.
24.
25.
26.
27.
28.
29.
30.

32.
33.
34.
35.
36.
37.
38.
39.
40.


42.
43.

44.
45.
46.
47.
48.

49.
50.


B.

Grease nipple ............................................................ STA3220
Washer ...................................................................... STA6018
Clamping Ring w/screw ............................................. R27-227E
Screw f/clamping ring ................................................ STA5627
Varispeed Collar ........................................................ R15-17.1
Ball Bearing ............................................................... R15-103
Movable Pulley .......................................................... R60-15Z
Bushing...................................................................... STA2505
Varispeed Belt ........................................................... R60-91
Reducer ..................................................................... R15-156
Drive Pin .................................................................... R60-285
Motor Pulley Bottom Half Assembly .......................... R60-13.1Z
Set Screw .................................................................. STA5602
Key (no attachment drive) ......................................... STA2011
Slotted Screw f/motor mount plate ............................ STA5018
Motor Mount Plate ..................................................... R60-61.1E
Mounting Bolt f/speed mechanism ............................ STA5345
Washer ...................................................................... STA6010
Bolt f/motor mount plate ............................................ STA5433
Washer ...................................................................... STA6026
Nut f/rack .................................................................. STA5815
Washers for spring fork ............................................. STA6040
Upper Fork................................................................. R20-19
Jam Nut f/ low speed stop ......................................... STA5810
Bolt f/high speed stop ................................................ STA5446
Jam Nut f/ high speed stop ........................................ STA5810
Flanged Nut f/low speed stop .................................... STA5895
Vari Spring ................................................................. W40P-275
Trestle ........................................................................ R20-26.1M4
Pin Bolt f/low speed stop ........................................... AR81-305
Washers for spring fork ............................................. STA6040
Flanged Nut f/low speed stop .................................... STA5810
Lower Fork................................................................. R27-16M4
Snap ring f/rack ......................................................... STA3407
Rack .......................................................................... R15-46.0
Bearing for Rack ........................................................ R15-18.2
Motor pulley shaft, assembly ..................................... R60-59Z
Upper Pedestal Pulley ............................................... R60-13.1M5
Snap Ring .................................................................. STA3410
Pedestal Shaft for V80............................................... R60-41Z
Pedestal Shaft for V100............................................. RN100-41.1
Key f/Pedestal Shaft .................................................. STA2024
Pulley f/Pedestal Shaft for V80 .................................. R100-128 (3V)
Pulley f/Pedestal Shaft for V100 ................................ RN100-128 (4V)
Ball Bearing ............................................................... 6205 2RS
Snap Ring .................................................................. STA3514
Bolt ............................................................................ STA5348
Washer ...................................................................... STA6033
Pedestal Arm for V80................................................. R100-6M5
Pedestal Arm for V100............................................... RN100-6M5
Spacer ....................................................................... RN100-143
Grease gun ................................................................ R15-142
Lower Pulley, assembly ............................................. R60-15.1Z
Motor pulley assembly ............................................... R60-59.1Z
Motor Pulley Bottom Half Assy .................................. R60-13.1Z
 
