Varimixer V80 - Attachment Drive Gearbox - V80 Only

29
Bearing Hub......................................................................................................................................R15-5
Worm wheel ......................................................................................................................................R20-9
Gear Case ........................................................................................................................................R15-10
Gear Case Cover..............................................................................................................................R15-11
Worm Gear .......................................................................................................................................R20-49
Gear Shaft ........................................................................................................................................R20-52Z
Attachment Drive Shaft # 12.............................................................................................................R15-50.6
Key ...................................................................................................................................................STA2032
Bearing .............................................................................................................................................R20-104
Seal ..................................................................................................................................................R20-107
Gasket ..............................................................................................................................................R20-300
Gasket ..............................................................................................................................................STA5908
Gasket ..............................................................................................................................................R20-301
Key ...................................................................................................................................................STA2007
Key ...................................................................................................................................................STA2011
Snap Ring .........................................................................................................................................STA3410
Screw................................................................................................................................................STA5018
Bearing .............................................................................................................................................6005 2RS
Bolt ...................................................................................................................................................STA 5433
Seal Washer .....................................................................................................................................STA5908
Washer .............................................................................................................................................STA6020
Washer .............................................................................................................................................STA6054
Lock Washer .....................................................................................................................................STA6056
Rubber Ring .....................................................................................................................................R15-211
Hub #12 ............................................................................................................................................R15-8.6M0
Bolt ...................................................................................................................................................STA5322
Thumbscrew #12 ..............................................................................................................................4R-125
Washer .............................................................................................................................................STA6056
Fig.

2.
3.
4.
5.
6.
7.
8.
9.










20.

22.
23.
24.
25.
26.
27.
28.

 
