Varimixer V80 - Page 42

42
Page Previous page: Next page: Total no. of pages:
Last print: Last edit: Page rev.: Project rev.:
Appr. (date/init): Eng. (proj/page): Dwg. no.: Case no.:Project title:
Customer: Page title: File name: Page ref.:
DCC: Scale:
VL-1L 6
2214-07-2016
Diagram
PCSCHEMATIC Automation
32.100-12.02.04 04-01-2018
5 7
02
CE / CE
&FS 1:1
1 2 3 4 5 6 7 8
BKBU BKBU
-B1
Boiler Bottom
BEBK BEBK
-B2
Boiler Top
-F4
Fuse
24V/8A
1112 1112
-K1
/5.8
7
+24VDC
1
0VDC
10
Ned
5
Out
9
Op
3
7
+24VDC
1
0VDC
10
Ned
5
Out
9
Op
3
-PCB2
Lift control unit
Overcurrent relay
5
Down
6
Down
3
Up
4
Up
5
Down
6
Down
3
Up
4
Up
-PCB1
PSB Front panel VL-1L
/5.5
+- +-
-D1
Rectifier Bridge
24VAC230VAC
24VAC230VAC
-TR1
Power supply to PCB 230VAC/24VAC
L1
/5.8
L2
/5.8
L+ 24VDC
/7.1
L- 0 Volt
/7.1
Therm istor
M
-M2
Lift motor 24 VDC
PE
/5.8
PE
/7.1
BL
BN
BL
BN
-W3
Lift motor cable

