VDIAGTOOL V210 - Page 11

Automotive Short And Open Finder
9
Fuse Socket or Connector
Figure 5
V210 Receiver
Black Negative Wire Red Positive Wire
V210 Transmitter
Figure 6
V210 Receiver
Black Negative
Wire
Red Positive
Wire
V210 Transmitter
