TCY3-T0121R Technical Data
Technical specifications
Doc: 70-000002 V1.0, 20101115 © Vector Controls GmbH, Switzerland Page 3
Subject to alteration
Power Supply
Operating Voltage 24 V AC/DC ± 10 %, 50…60 Hz
Power Consumption Max. 3 VA
Electrical Connection Terminal Connectors,
wire 0.34…2.5 mm
2
(AWG 24…12)
Internal rectification:
Signal ground = power ground
Half wave rectified
Security transformer required
Clock backup 24 hours (Deluxe version only)
Signal inputs
Analog Input
Input Signal
Resolution
AI1
0...10 V or 0...20 mA
9.76 mV or 0.019 mA (10 bit)
Temperature Input
Range Int. NTC: 0…50 °C (32…122 °F)
Ext. NTC (Sxx-Tn10 sensor): -40…140 °C (-40…284 °F)
Accuracy -40…0 °C (-40…32 °F): 0.5 K
0…50 °C (32…122 °F): 0.2 K
50…100 °C (122…212 °F): 0.5 K
> 100 °C (> 212 °F): 1 K
Humidity Input: (-H Version only)
Range
Accuracy at 55 % r.H.
Hysteresis
Repeatability
Stability
H1 Thermoset Polymer-Based Capacity
0…100 % r.H.
± 3.0 % at 25 °C (77 °F)
± 3 % between 15…90 % r.H.
± 0.5 %
± 0.5 % / year if used within 0…50 °C (32…122 °F)
Signal outputs
Analog Outputs
Output Signal
Resolution
Maximum Load in voltage mode
AO1
DC 0...10 V or 0...20 mA (250 Ω max.)
9.76 mV resp. 0.019 mA (10 bit)
10 mA
Relays Outputs
AC Voltage
DC Voltage
DO1, DO2
0…48 VAC, 2 (1.2) A max. each output
0…30 VDC, 2 (1.2) A max. each output
Environment
Operation
Climatic Conditions
Temperature
Humidity
To IEC 721-3-3
class 3 K5
0…50 °C (32…122 °F)
<95 % r.H. non-condensing
Transport & Storage
Climatic Conditions
Temperature
Humidity
Mechanical Conditions
To IEC 721-3-2 and IEC 721-3-1
class 3 K3 and class 1 K3
-25…70 °C (-13…158 °F)
<95 % r.H. non-condensing
class 2M2
Standards
conform according to
EMC Standard
89/336/EEC
EMEI Standard 73/23/EEC
EN 61 000-6-1/ EN 61 000-6-3
Product standards
Automatic electrical controls for
household and similar use
Special requirement on
temperature dependent controls
EN 60 730 –1
EN 60 730 – 2 – 9
Degree of Protection IP30 to EN 60 529
Safety Class III (IEC 60536)
Cover, back part
Mounting Plate
Fire proof ABS plastic (UL94 class V-0)
Galvanized Steel
General
Dimensions (H x W x D) Front part: 88 x 88 x 21 mm (3.5” x 3.5” x 0.8”)
Power case: ø 58 x 32 mm (ø 2.3” x 1.3”)
Dimensions (H x W x D), U-version Front part: 112 x 73 x 15 mm (4.4” x 2.9” x 0.6”)
Power case: ø 58 x 32 mm (ø 2.3” x 1.3”)
Weight (controller only) 180 g (6.3 oz)
Weight (including package) 260 g (9.2 oz)
