Appendix B: Universal Sensor Mounting Kit Mounting Sensors
B-4
Figure B-4. Mounting the Sensor using Two Extension Brackets
3/8-16 Spring nut
Support bar
Extension
bracket
Extension
bracket
Clamp
sensors\extbkt.eps
Sensor
1/4-20 x 3/4 hex bolt w/
washer and nut
3/8-16 x 7/8 hex bolt
1/4-20 x 3/4 hex bolt
w/ washer and nut
(not shown)
1/4-20 x 1-1/2
machine screw w/
washer and nut
