Veeder-Root TLS-350 Series User Manual

1
Introduction
This manual describes site preparation and installation procedures for the following consoles:
FIXED-FEATURE CONSOLES
• Veeder-Root TLS-300 Consoles,
• ProPlus Consoles
• Gilbarco EMC Basic Consoles
MODULAR CONSOLES
• Veeder-Root TLS-350 Series Consoles,
• ProMax Consoles
• Gilbarco EMC Consoles
This manual assumes that you are installing the console in a new site (before pavement is put down and with no
wiring runs in place). Among the topics covered are:
• Site layout considerations.
• Installing the console and connecting wiring from the AC power panel.
• Probe installation procedures.
• Sensor installation procedures.
• Installing wiring conduit between the console and the probes and sensors.
• Probe and sensor field junction box wiring diagrams.
• Attaching sensor wiring to the console.
Contractor Certification Requirements
Veeder-Root requires the following minimum training certifications for contractors who will install and setup the
equipment discussed in this manual:
Installer (Level 1) Certification: Contractors holding valid Installer Certification are approved to perform wiring
and conduit routing; equipment mounting; probe, sensor and carbon canister vapor polisher installation; wireless
equipment installation; tank and line preparation; and line leak detector installation.
ATG Technician (Level 2/3 or 4) Certification: Contractors holding valid ATG Technician Certifications are
approved to perform installation checkout, startup, programming and operations training, system tests,
troubleshooting and servicing for all Veeder-Root Series Tank Monitoring Systems, including Line Leak Detection.
In addition, Contractors with the following sub-certification designations are approved to perform installation
checkout, startup, programming, system tests, troubleshooting, service techniques and operations training on the
designated system.
• Wireless 2
• Tall Tank
VR Vapor Products Certification: Contractors holding a certification with the following designations are
approved to perform installation checkout, startup, programming, system tests, troubleshooting, service techniques
and operations training on the designated system.
• ISD – In Station Diagnostics
• PMC – Pressure Management Control
• CCVP - Veeder-Root Vapor Polisher
