Page #11 background imageLoading...
Page #11 background image
11
VEGAPULS 6X
66216-EN-220518
The VEGAPULS 6X must be connected via suitable cable gland or conduit systems that are in
conformity with the requirements of the standards and provided with a separate type approval
certicate. When connecting the VEGAPULS 6X to conduit systems, the corresponding sealing
facility must be connected directly to the housing. Keep the type and size of the threads in mind:
The thread names are mentioned on the type label
Unused openings must be covered according to the standards. The red thread or/dust covers
screwed in when the instruments are shipped (depending on the version) must be removed
before setup and replaced by cable entries or closing screws suitable for the respective ignition
protection type and IP protection.
The connection cable of VEGAPULS 6X has to be wired x and in such a way that damages can
be excluded
Lids must not be opened if there is a hazardous atmosphere. The housing lids are marked with
the warning label:
WARNING - DO NOT OPEN WHEN AN
EXPLOSIVE ATMOSPHERE IS PRESENT
7 Electrostaticcharging(ESD)
In case of instrument versions with electrostatically chargeable plastic parts, the danger of electro-
static charging and discharging must be taken into account!
The following parts can charge and discharge:
Lacquered housing version or alternative special lacquering
Plastic housing, plastic housing parts
Plastic process ttings
Plastic-coated process ttings and/or plastic-coated sensors
Connection cable for separate versions
Type label
Take note in case of danger of electrostatic charges:
Avoid friction on the surfaces
Do not dry clean the surfaces
The instruments must be installed in such a way that the following can be ruled out:
electrostatic charges during operation, maintenance and cleaning.
process-related electrostatic charges, e.g. by measuring media owing past
The warning label indicates danger:
WARNING - POTENTIAL ELECTROSTATIC
CHARGING HAZARD - SEE INSTRUCTIONS
8 Electricaldata
For the VEGAPULS 6X in ignition protection type dust ignition protection by enclosure (IIIC) applies:
Powersupplyandsignalcircuit:terminals1[+],2[-]
The following values must be observed or taken into account:
Supply via a circuit with limited power (max. 100 W, see operating instructions), e.g. a class 2 power
supply unit common in North America
U = 12 … 35 V DC
