VEGAPULS 6X
66216-EN-220518
s Food/pharmaceuticalcerticate
X without
* with
t Shipapproval
X without
* with
u SecondaryLineofDefense
X without
S with
3 Applicationarea
Overviewofthedierentapplicationareas:
VEGAInstrument 3D(EPLDc) 2D(EPLDb) 1/2D(EPLDa/Db) 1D(EPLDa)
Ex Zone 22
Ex Zone 21
Ex Zone 20
ApplicationareaofVEGAPULS6X(electronicsversionH):
Type code Explosion
group
Typeofprotectionmarking
Electronics version "H" - Two-wire 4 … 20 mA/HART
PS6X(*).2*W**B/T/F/C******H* R****** IIIC II 1D, 1/2D Ex ta, ta/tb IIIC T* Da, Da/Db IP66
PS6X(*).2*W**B/T/F/C******H* J****** IIA, IIB, IIC
IIIA, IIIB, IIIC
II 1/2G, 2G Ex db IIC T6…T1 Ga/Gb, Gb
II 1D, 1/2D Ex ta, ta/tb IIIC T* Da, Da/Db IP66
ApplicationareaofVEGAPULS6X(electronicsversionA):
Type code Explosion
group
Typeofprotectionmarking
Electronics version "A" - Two-wire 4 … 20 mA/HART with overvoltage arrester
