VEGAPULS 6X
66216-EN-220518
f Antennaversion
B Plastic horn antenna
T Thread with integrated antenna system
F Flange with plastic plating
C Flange with lens antenna
g Additionalequipment
X without
K with rinsing air connection
V with purging connection with reux valve
1 Antenna system DD-lacquered
hi Material/Seal/Processtemperature
AA PEEK/FKM (SHS FPM 70C3 GLT) / -40 … +150 °C
AB PEEK/FKM (SHS FPM 70C3 GLT) / -40 … +200 °C
AC PEEK/FFKM (Kalrez 6230) / -15 … +150 °C
AD PEEK/FFKM (Kalrez 6230) / -15 … +250 °C
AE PEEK/FFKM (Kalrez 6375) / -20 … +150 °C
AF PEEK/FFKM (Kalrez 6375) / -20 … +250 °C
AG PEEK/FFKM (Perlast G75B) / -15 … +150 °C
AH PEEK/FFKM (Perlast G75B) / -15 … +250 °C
AJ PEEK/FFKM (Perlast G74S) / -15 … +150 °C
AK PEEK/FFKM (Perlast G74S) / -15 … +250 °C
AL PEEK/EPDM (COG AP302) / -40 … +150 °C (for lens antennas)
AL PEEK/EPDM (A+P 70.10-02) / -55 … +150 °C (for threaded version)
AT PP/PP / -40 … +80 °C
AU PP/FKM ( SHS FPM 70C3 GLT) / -40 … +80 °C
AV PP/EPDM (COG AP310) / -40 … +80 °C
AW PTFE/PTFE / -60 … +150 °C
A4 PTFE/PTFE / -60 … +200 °C
AX PTFE/PTFE / -196 … +200 °C
AY PTFE (8 mm)/PTFE / -60 … +150 °C
A5 PTFE (8 mm)/PTFE / -60 … +200 °C
AZ PTFE (8 mm)/PTFE / -196 … +200 °C
A2 PFA (8 mm)/PFA / -60 … +150 °C
A3 PFA (8 mm)/PFA / -60 … +200 °C
j Housing/Protection
A Aluminium single chamber / IP66/IP68 (0.2 bar)
H Special colour Aluminium single chamber / IP66/IP68 (0.2 bar)
