10. Error information
Display can warn bike faults. When faults are detected, error code will be shown on interface and
blink at 1Hz. When error code is shown, button functions will not be affected, meaning interfaces can
be shown normally by pressing buttons. If no button operation after 5s, the display will returns to the
error code interface.
Error code interface as shown below:
Error code information table:
throttle doesn't turn back to zero position (stay
on the high position)
Check if the throttle
turned back
failure of motor's hall signal wire
failure of motor's phase wire
failure of the motor's temperature sensor
failure of the current sensor
failure of the temperature of the battery
Controller temperature is too high,
and reaches the protection point
failure of the speed sensor
Check the install
position of the speed
sensor
Failure of BMS communication
Check connector to
controller
