③ Unit: Km / miles
④ Speed: Real-time speed（SPEED）、 maximum speed（MAX）、 average speed（AVG）
⑤ Battery indicator with percentage display
⑥ Range: Endurance mileage（*available if BMS provides necessary info）
⑦ Headlight on/off status indication and control
⑧ Mileage: Subtotal mileage(TRIP), total mileage (ODO)
⑨ Walk assist function
⑩ Parameters setting and advanced setting
⑪ Error code indication
3. Installation
① Open the display locking clip, set the display in the left handlebar (standard handlebar size:Φ22.2)
Adjust to a position easy to operate, using M3 hex set to screws and tighten. Tightening torque: 0.8N.m.
*Note: Damage caused by excessive torque is not covered by the warranty.
② Connect the 5 pin plug to the docking plug of the controller as marked
