4.2 Basic interface and operation
① Display adopts 4 buttons: power button、M button、 button、 button
② Standard Outlet is a board end connector, which is convenient for after-sales maintenance and
replacement
③ 1.3 inch OLED dot matrix display meets the need for customization of the boot interface and UI
interface
4.3 Function interface introduction
Boot interface and basic function interface
Boot logo interface is displayed for 3 seconds after display is turned on. When the
M button
Power button
Adjust button
5 Pin Plug
Basic interface
Boot logo interface
customization available upon
request
Battery indicator
Headlight indicator
Speed display
Subtotal mileage
Power assist level
Boot logo interface
Basic interface
Bluetooth
