C-3
11/2007
* NOTE: WHEN ORDERING FOAMED CABINET ASSEMBLY OR BASE COVER PANEL, PLEASE
PROVIDE 9- CODE AND MANUFACTURER’S DATE CODE.
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-10.
CABINET ASSEMBLY
ITEM NO DESCRIPTION QTY PART NO
1 FOAMED CABINET 1 *
2 CABINET LATCH 3 1130807
3 SCREW, #10 X 3/8” CR TAP 11 V802212
4 RAMP ASSEMBLY 1 1133925
RAMP, DOOR 1 1130868
THUMB SCREW, 1/4-20 X .5, RAMP 1 1127060
5 LEVELING BOLT 4 1059902
6 BASE COVER PANEL 1 *
7 REFRIGERATION ASSEMBLY (SEE PAGE C-4) 1 ~
8 CHANNEL-TRAY SUPPORT 2 1126639
9 LIGHT ASSEMBLY (SEE PAGE C-5) 1 ~
10 ANGLE MOUNT, VERTICAL PANEL 3 1131149
11 AIR DUCT ASSEMBLY 1 1127962
12 POWER DISTRIBUTION ASSEMBLY (SEE PAGES C6-C9) 1 ~
13 VERTICAL FOAM PANEL 1 1133699
14
PANEL,SCREEN,REAR,41.5” 1 1146906
PANEL,SCREEN,REAR,34” 1 1148771
15 #10 X 1/2” SELF DRILLLING SCREW 4 V801489
