Vendo VUE 30 Manual

C-7
11/2007
POWER DISTRIBUTION ASSEMBLY, 115V
FOR A COMPLETE LIST OF HARNESSES, PLEASE SEE PAGE C-10.
ITEM NO DESCRIPTION QTY PART NO
1 POWER DISTRIBUTION ASSEMBLY, 115 V 1 1128752
2 PANEL, POWER DISTRIBUTION 1 1128743
3 TRANSFORMER, 24 VAC 1 1111201
4 FAN, PWR DISTRIBUTION 1 1127890
5 BUSHING 4 1116634
6 PLATE, PWR SUPPLY 1 1128356
7 POWER SUPPLY, 24V DC 1 1137384
8 STANDOFF 4 V802255
9 SCREW, 10-16 5/16 HEX HEAD 13 V801421
10 SCREW, 6-32 1/4 4 V802243
11 RELAY, 24 VOLT DC 3 1128801
12 SCREW, 10-16 1/2 HEX HEAD 4 V801422
13 FUSE, 3.15 AMP SLOW BLOW 1 1127484
14 HOLDER, FUSE 1-1/4 X 1/4 1 1128474
15 HOLDER, FUSE 5X20MM 1 1128473
16 FUSE, 0.8 AMP/250V, 3AG 1 1053864
17 BOX, DISTRIBUTION PANEL 1 1131242
18 BALLAST, ELECT. 1 1144522
