7
OR
BACKLIGHT
If the backlight is not illuminated, the first button pressed (no matter which button)
shall turn on the backlight. The backlight remains illuminated for 10 seconds
after the last button pressed.
To change the operation mode of the ventilation unit, press the UP or DOWN arrow
button. Operating mode label will then scroll up or down on LCD screen.
OPERATING MODES
OFF
Put the unit on stand-by mode, so it will only respond to auxiliairy controls (if present).
On LCD screen, only the House is visible showing the control is powered on. This is
the factory default mode.
VC0117
MIN
Air is exchanged with the outside on low speed.
MAX
Air is exchanged with the outside on high speed.
20 MIN/H
The ventilation unit exchanges air intermittently on a one hour cycle as follows: OFF
for 40 min. and then exchange air during 20 min. on low speed. Repeat cycle after the
20 min. of air exchange.
2.2 OPTIONAL MAIN CONTROLS
2.2.1 DECO-TOUCH
2. CONTROLS (CONT’D)
