TRAILER SET-UP REQUIREMENTS - GENERAL
Note:
1. Before operating the slide-out room, level the trailer front-to-rear and
side to side.
2. Extend all stabilizer jacks to make solid contact with the ground and/
or on solid blocks. Placing stabilizer jacks onto a hard surface allows
the coach to remain square and assure a good weather tight seal
between the room and trailer sidewall.
BELOW FLOOR SLIDE SYSTEM
Under floor slide-out mechanism steel bars are welded to the frame
members. A “cog” track is welded to bottom side of cross member,
matching with a gear attached to drive shaft, “LCS (Lippert Component
System.) As motor turns, a actuator moves the gear on the track
( ram ). A cross shaft, front to rear ram connects the second ram,
moving the opposite end of slide. Mechanism operates the same, flush
or standard floor.
ABOVE FLOOR SLIDE-OUT
All components are located inside of coach, under dinette or sofa. Base
is attached to the floor and sidewall. Top portion has a “cog” track
attached to a “ram” which matches to gear on motor. As motor runs, it
moves the slide in or out, as you choose. On a large slide with 2 units, a
cross shaft will connect both units, operated by one motor. Access to
these components is inside of coach, under slide floor.
♦ Always make sure that the trailer is level before operating the slide-out room.
♦ Always make sure there are no obstructions blocking the path of the room when it
is moving.
♦ Always make sure that the room path is clear of people and objects before operat-
ing.
♦ Always keep away from the slide rails under the coach when the room is in mo-
tion.
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN SERIOUS INJURY
WARNING
!
