4. To end operation close valve (s) on the faucet and allow water to
drain from the shower head.
5. Close the valve on the shower head.
Any water remaining in the hose will drip or run out of the vacuum
breaker. This is NOT a leak but performs as intended. Water in the
ABS plastic box will drain out along outer edge.
The shower head can be removed to drain the hose faster.
Reassemble and place onto bracket. Keep the door closed when
not in use for sanitary reasons.
Fresh Water Line
Two lines, generally red for hot and blue for cold, transport water
through out the coach. Valves to direct flow are near city water fill or
pump area. Connector elbows and tees are plastic or copper, and
are held together with compression rings for no leakage.
Low-Point Drains
Low-Point drains are placed on recreational vehicles to drain water
lines, tanks, and water heater to prepare coach for winterization and
sanitizing systems.
Fresh water supply tanks will have their own separate drains under
the floor and/or frame, with a valve to be opened to drain, over flow
drain line may be close by.
Plumbing lines also have Low-Point drains located in various areas.
You may find them (2) for hot and cold water lines coming out of
storage areas, outer metal skirt, through under belly covers, control
centers, etc. Water should always drain out to the ground, not into
underbelly cover.
POTABLE WATER ONLY. SANITIZE, FLUSH AND DRAIN
BEFORE USING. SEE INSTRUCTION MANUAL. FAILURE TO
COMPLY COULD RESULT IN DEATH OR SERIOUS INJURY.
WARNING
!
