MANUAL OVERRIDE:
BELOW FLOOR SLIDE OUT
Should a power failure occur (no 120 volt AC power or the battery looses
its charge), follow the directions listed.
There is a 1/2” shaft coming through the main rail of frame. On the
end of the shaft is a 3/4” nut attached. Use a 3/4” socket with extension
and ratchet to move the slide. On some units the stabilizer jack crank
handle will also work on this shaft with the attached 3/4” nut.
ABOVE FLOOR SLIDE-OUT
Manual Override (Single or Double Rams)
Should 12 volt power fail and there is no 120 volt AC power available,
follow the directions listed.
Access to the ram is under the floor of slide, sofa or dinette, and is from
the front. Lippert Component System has a smaller motor, less draw and
requires a 5/8” socket, ratchet and probably an extension shaft.
BLINDS
Any blinds with loose cords, such as mini-blinds CANNOT be installed in
bunks designed and built for young children.
Night shades installed, have cords anchored to lower part of window and
need to be secured for operation.
VENTURE RV recommends these shades be in the UP position for
travel to avoid lower metal holder being in contact with garnish on
window.
Because operating the slide-out draws up to 15 amp current from the battery, some
source of supplemental charging should be operating while extending or retracting
the slide out
CAUTION
!
