64
30-A, 125-V, 2-pole, 3-wire,
grounding type
ELECTRICAL SYSTEM
General Information
The electrical system in your recreational vehicle is designed for using
both 120 volt AC (alternating current) and 12 volt DC (direct current)
capabilities. All installations and designs are built to comply with
safety requirements of ANSI standard 1192, National Electric Code
and Canadian Standards Association.
This model manufactured by VENTURE RV has 30 amp system.
Highly recommend that your RV electrical connection, is not
plugged into a household outlet.
Changes and Modifications
Any changes, alternations, additions, and/or modifications need to be
performed by qualified electrical technicians, using only approved
components which meet safety and code requirements. This includes
owners, dealers, etc. who desire to make changes. The manufacturer
is not responsible for any changes, or alterations, made to the 120
AC system of the coach.
120-Volt A/C System
Power Cord 30 AMP
The 30 amp rated power cord is not pre-wired into the breaker box.
Open the hatch door as shown, on the exterior of the coach. Pull cord
out from interior storage and attach it to incoming 120-volt power
source and your RV.
This cord places 120 AC volt power into your breaker distribution
center, as built into your coach, also rated at 30 amps.
Energy will enter through the main breaker and is distributed through
circuit breakers to the wall receptacles and appliances. This power
cord will be approximately 26 to 28 feet in length. Each cord has the
correct gauge of wire to carry the correct voltage to the coach.
