DEVICE DRIVERS

ledOn

M

X

800 SERIES PROGRAMMERS GUIDE 137

ledOn

ledOn() is used to turn 1 or more of the LEDs on.

A bit mask is used to select the LED(s) to turn on.

Prototype

void ledOn(int parm)

Parameters

parm

To turn on all three LEDs,

set PARM = LED1|LED2|LED3

LED1 Top LED

LED2 Middle LED

LED3 Bottom LED
