CONTACTLESS RF CARD READER MODULE

RFCRSetAntenna()

800 SERIES PROGRAMMERS GUIDE 237

RFCRSetAntenna()

Configures the Antenna control of the RFCR module.

Prototype

int RFCRSetAntenna(short onOff);

Parameters

Return Values

onOff 0 = Disable the RF Antenna

1 = Enable the RF Antenna

0 Success, for OFF

< 0 Error

-EBADF if not initialized

> 0 NAK status
