DEVICE DRIVERS

ledOff

138 M

X

800 SERIES PROGRAMMERS GUIDE

ledOff

ledOff() is used to turn 1 or more of the LEDs off.

A bit mask is used to select the LED(s) to turn off.

Prototype

void ledOff(int parm)

Parameters

parm

To turn off all three LEDs,

set PARM = LED1|LED2|LED3

LED1 Top LED

LED2 Middle LED

LED3 Bottom LED
