18
© VeriFone, Inc. All rights reserved.
Installation Guide P400/P400 Plus
• BT/Wi-Fi functions are unavailable.
• The maximum USB cable length supported is 3m (CBL282-038-02-B).
• In CTLS payment mode, the microprocessor operating frequency is reduced to
300 MHz until the PINpad exits CTLS mode.
• Multi-media function (video playback or audio function) has to be switched off
by user or customer app when CTLS (Contactless) payment mode is activated.
Other modes of payment like smart card and MSR payment can be supported.
Cable
Connections
The P400 has several cabling scenarios, depending on what it connects to:
1 Connection to Another Verifone Terminal
2 RS-232 Connection Using an External Power Brick
3 Direct USB Connection
4 Powered USB Connection
5 Ethernet Connection with External Power Brick.
Attaching a
Cable Connector
to the P400
Before going into each cabling scenario, the cables first have to be
attached to the P400. To attach a cable to the terminal, follow steps 1-2 in
the
Installing or Changing MSAM/uSD Card section to open the
compartment door, then attach the 28-pin connector of the cable to the
terminal. Slide back compartment cover and tighten the captive screw as
shown in the Figure 4 - C.
CTLS payment mode is defined as the state of the device where RF (Radio
Frequency) transmission is broadcasting to allow for a CTLS payment. This is
activated either during the scanning of items or at the completion of scanning
items during the checkout
process, depending on how the application sets it up. As soon as checkout is
complete, the device exits CTLS payment mode and remains off until activated
for the next checkout.
Turn off or unplug the terminal when connecting or disconnecting the device to avoid
device memory corruption and data loss.
Refer to the controlling device instructions for any terminal-specific warnings.
Éteignez ou débranchez le terminal lors de la connexion ou de la déconnexion de
l'appareil pour éviter la corruption de la mémoire de l'appareil et la perte de données.
Reportez-vous aux instructions du dispositif de contrôle pour tout avertissement
spécifique au terminal.
