P200/P400 REFERENCE GUIDE 15
CHAPTER 2
Using the PINpad Keys
Before proceeding to other tasks, familiarize yourself with the operational features
of the keypad to enter data.
This section describes how to use the keypad, which consists of a 12-key Telco-
style keypad with three color-coded keys below the keypad. Using these keys you
can perform all data entry tasks described in this manual. For added convenience,
the keypad is automatically back-lit when you power on the device.
Figure 3 Front Panel Key Arrangement on P400/P400 Plus
TELCO STYLE
KEYPAD
ENTER
CLEAR
CANCEL
