SETUP
Installing or Replacing MSAM and Micro SD Cards
16 V205C INSTALLATION GUIDE
2 Remove any protective plastic wrap and place the unit on a table or
countertop.
3 Remove the clear protective film from the display.
4 Replace all the packing materials, close the lid, and save the carton for
repacking or moving the V205c unit in the future.
Installing or
Replacing
MSAM and
Micro SD Cards
You may need to install or replace the multiple security access module (MSAM),
Micro Secure Digital (SD) cards.
Opening Card
Compartment
Use the following steps to get access to the MSAM and Micro SD card
compartment:
1 Place the terminal face down on a soft and clean surface to protect the display
from scratches.
2 Push the locking tab and swing out the compartment cover.
Figure 5 Accessing Cardholders
3 The MSAM and Micro SD cardholders are now accessible.
Changing or
Installing MSAMs
To change or install MSAM cards:
1 Use steps 1 to 2 of Opening Card Compartment to get to the MSAM
cardholder.
Do not use a unit that has been tampered with or otherwise damaged. This unit
comes equipped with tamper-evident label. If a label or component appears
damaged, immediately notify the shipping company and your Verifone
representative or service provider.
Observe standard precautions in handling electrostatically sensitive devices.
Electrostatic discharges can damage the equipment. Verifone recommends using
a grounded anti-static wrist strap.
