SETUP
Installing or Replacing MSAM and Micro SD Cards
V205
C INSTALLATION GUIDE 17
2 Remove the old card, if any, and insert the MSAM card carefully into the slot
(with the gold contacts facing downward) until fully inserted.
Figure 6 Inserting MSAM Card
3 If you are finished replacing or inserting cards, put the rear cover back in
place.
Changing or
Installing Micro SD
Card
To change or install Micro SDcards:
1 Use steps 1 to 2 of Opening Card Compartment to get to the Micro SD
cardholder.
2 Remove the old card, if any, and insert the Micro SD card carefully into the slot
(with the gold contacts facing downward) until fully inserted.
Figure 7 Inserting Micro SD Card
Insert the card with the card’s gold contacts facing away from you, toward the unit.
Take note of the notched edge on the MSAM card for quick orientation.
Insert the card with the card’s gold contacts facing away from you, toward the unit.
