VeriFone Vx520 User Guide

Navigating the Terminal
4
Function Keys:
Use function keys to
select from the menu.
03/31/17 16:00
Sale
Settlement
Void
O
P
E
N
Batch:
Displays when batch
is open.
C
S
Hot Key Functions:
Use hot keys beneath
the display to select
additional functions.
1
2
3
4
Command Keys:
Use command keys to
Direct terminal.
ENTER KEY:
Press to continue
BACKSPACE KEY:
Remove incorrect value
CANCEL KEY:
Return to main menu
Smartcard Reader:
Insert card face up
with chip towards
terminal .

VeriFone Vx520 Specifications

General

Peripheral Ports	RS-232, USB
Power Supply	100-240 VAC, 50/60 Hz
Operating Temperature	0°C to 50°C (32°F to 122°F)
Processor	400 MHz ARM11
Memory	128 MB Flash
Display	128 x 64 pixel LCD with backlight
Connectivity	Dial-up, Ethernet
Card Readers	EMV chip
Contactless	Optional
Printer	Integrated thermal printer
Security	PCI PTS
SAM Slots	3
Compliance	EMV Level 1 & 2, RoHS
