Sivu
7(36)
28.9.2016
1.4 Technical data
Processor: 400 MHz | ARM11 32-bit RISC
Operating System: Verix OS
Display: 3.5” QVGA | capacitive touch screen
Memory: 192MB (128MB Flash, 64MB SDRAM)
Connections: HSPA+ 3G radio | 5GHz Wi-Fi & 2.4 GHz Wi-Fi | Bluetooth 4.0
Printer: 30 lps | paper roll width 57mm, diameter 40 mm
Readers: Triple track MSR | landed smart card
Contactless: ISO14443 A&B | MiFare | ISO18092 | EMVCo L1 certification
Ports: Micro USB | integrated charging
Other standard
features: 2 SAM slots | dual SIM | GPS | embedded audio
Connectivity: GPRS, 3G, WLAN, Bluetooth
Security: PCI 3.0
Battery: 3,7 V DC | 2450 mAh
Size: Terminal: 167mm L x 78mm W x 55mm H; 372g weight |
Base Station: 143mm L x 86mm W x 43mm H; 157g weight
Environmental: 0º to 50º C operating temperature | -20º to 60º C storing temperature |
5% to 90% relative humidity, non-condensing
1.5 Connecting cables
Plug the power cord into the Micro USB port.
