Table 2-4
53xx factory default port configuration (continued)
Optimized duplication and
replication
FTMSHBA
configuration
Not applicableSlots 5 and 6, Port 1 - target53xx C
Slot 2, Port 1 - initiator
Slot 2, Port 2 - target
Slots 5 and 6, Port 1 - target53xx D
Slots 2 and 3, Port 1 - initiator
Slots 2 and 3, Port 2 - target
Slots 5 and 6, Port 1 - target53xx E
When you enable the appliance as a target for optimized duplication and replication,
the following applies:
■ The factory default port configuration is used if you have not customized the
port mode.
■ The customized port configuration is used if you have changed the default port
mode.
By default a 52xx or 53xx appliance is not enabled as a target for optimized
duplication and replication over FT. The port configuration is not functional until the
feature is enabled.
See “About the NetBackup 5230 rear panel configurations” on page 18.
See “NetBackup 5240 Appliance I/O configuration options” on page 20.
See “NetBackup 5330 Appliance compute node PCIe slot I/O configuration options”
on page 23.
See “Supported Fibre Channel port configurations for the NetBackup 5220 and
5230 appliances” on page 37.
See “Supported Fibre Channel port configuration for the NetBackup 5240 appliances”
on page 43.
See “Supported Fibre Channel port configurations for the NetBackup 53xx
appliances” on page 47.
36About the HBA port mode configuration
About FTMS reserved HBA ports and the factory default port mode configuration
