Table 2-7
Supported NetBackup 53xx PCIe card slot configurations and
FC options (continued)
Supported FC optionsCard slot and type
Port 1
■ SAN Client - target
■ Optimized duplication - initiator or target
■ Auto Image Replication - initiator or target
■ Tape out - initiator
■ NetBackup for VMware - initiator
Port 2
■ SAN Client - target
Note: If Port 1 is in the initiator mode, Port 2 cannot be
set to the target mode. Port 2 can only be configured for
the target mode when the 4 target port Fibre Channel
connection option is selected.
■ Optimized duplication - initiator or target
■ Auto Image Replication - initiator or target
■ Tape out - initiator
■ NetBackup for VMware - initiator
Use only one option on each port.
This slot is populated with an FC card on 5230 HBA
configurations B, C, D and E.
On 53xx HBA configurations C, D, and E, this slot is reserved
for FTMS. If you enable SAN Client FTMS with those three
configurations, Port 1 is changed to target mode for SAN
Client by default.
Slot 6
10Gb NIC or 8Gb FC HBA
See “About NetBackup SAN Client and Fibre Transport” on page 9.
See “About Fibre Transport for optimized duplication and Auto Image Replication
between appliances” on page 11.
See “How to determine appliance HBA WWPNs” on page 51.
See “About Fibre Transport paths for NetBackup appliances” on page 27.
See “Supported Fibre Channel port configuration for the NetBackup 5240 appliances”
on page 43.
See “Supported Fibre Channel port configurations for the NetBackup 5220 and
5230 appliances” on page 37.
50About the HBA port mode configuration
Supported Fibre Channel port configurations for the NetBackup 53xx appliances
