TROUBLESHOOTING TIPS
5.0g/ FRONT UNIFIED BUTTON
The front panel’s Unified Button allows quick access to the Wi-Fi
Protected Setup (WPS) feature and handset paging/pairing mode.
In addition, the Unified Button provides a visual display of the
Fios Home Wi-Fi Extender’s current condition. Refer to the chart
below for details.
Condition Status LED Color Fios Home Wi-Fi Extender
Normal WHITE Normal operation (solid)
Router is booting. (fast blink)
BLUE Pairing mode (slow blink)
Pairing successful (solid)
GREEN Wi-Fi has been turned o. (solid)
Issue(s) YELLOW No internet connection (solid)
Wi-Fi Extender is too far from the Router.
Poor backhaul signal (slow blink)
Wi-Fi Extender is too close to the Router.
Poor Wi-Fi coverage (fast blink)
RED Hardware/System failure detected (solid)
Overheating (fast blink)
Pairing Failure (slow blink)
Power OFF Power o
