Step 9 (Mount the cartridge holder)
Mount the cartridge holder TA onto the valve.
Screw it tight with the 2 screws for the cartridge
holder (torque 40 – 50 cN.m). Use the MDT 329
or a hexagon socket key size 2.
Hook the heater connection of the fluid box
into the cartridge holder (see arrow).
