VERSA HERO SERVICE MANUAL
15
9. Radio Assembly and Disassembly
9.1 Assembly and Disassembly
1. Remove antenna. Turn antenna counterclockwise.
2. Remove the battery. Press down the battery latch at the bottom of the transceiver then
pull the battery.
3. Remove Power/ Volume Knob. Pull the knob.
