EVX-S24 OPERATING MANUAL 29
DUTY
The Duty function is specifi c to paging operation. When
Duty mode is “ON” the user will hear all traffi c (specifi c
to sub audio signaling) on the paging channel. The paging
alert will sound when the programmed 2-Tone or 5-Tone
sub audio signal is received.
If Duty mode is “OFF”, normal radio traffi c is not heard
on the paging channel. The radio will only unmute and
sound the paging alert with the programmed 2-Tone or
5-Tone signal is received.
ID CHECK
This function allows you to confi rm the logged ID of the
operating system which set to the current operating chan-
nel. Available operating system are 5-Tone ID, DTMF ID,
MDC1200® ID, and Digital ID.
Press the assigned
PF
key to display the logged ID.
Press the
[
]
/
[
]
keys to select the logged ID.
Press and hold in the
[
SIDE
]
key to toggle the display
between the “ID Code display” and “Channel Tag dis-
play”.
Press the
[
SIDE
]
key to revert to the normal channel
indication.
TEXT MESSAGE
You may receive/send the message from/to other radio.
See page 36 for more information of the message feature.
REMOTE HALT TX
(
TX I
NTERRUPT REMOTE DEKEY
)
This feature allows a priority user (assigned with the pro-
gramming software) the ability to halt or “interrupt” any
current transmission. The channel is then open for a prior-
ity message to be sent. Transmit Interrupt functionality
ensures connection of critical messages.
Press the assigned
PF
key to halt any current transmis-
sion. The channel will clear, then press the
PTT
button to
transmit the priority message.
ADVANCED OPERATION
