DESCRIPTION

VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.

REF.

LOT.

SIDE

LAY ADR

MAIN Unit

C 1069 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b1

C 1071 CHIP TA.CAP. 0.1uF 35V TEESVA1V104M8R K78160025 1- B d1

C 1072 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A D1

C 1073 CHIP CAP. 1uF 10V B ECJ2FB1A105K K22100806 1- B d1

C 1073 CHIP CAP. 1uF 10V B GRM21BB11A105KA01L K22100802 73- B d1

C 1074 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B d3

C 1075 CHIP TA.CAP. 2.2uF 6.3V TEESVA0J225M8R K78080009 1- B d3

C 1076 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d3

C 1077 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d3

C 1078 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- B d2

C 1079 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d3

C 1080 CHIP TA.CAP. 2.2uF 6.3V TEESVA0J225M8R K78080009 1- B d3

C 1081 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- B d2

C 1082 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d3

C 1083 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d2

C 1084 CHIP TA.CAP. 1uF 16V TEESVA1C105M8R K78120009 1- B d2

C 1085 CHIP CAP. 10pF 50V CH GRM1552C1H100JZ01D K22178212 1- B a2

C 1087 CHIP CAP. 56pF 50V CH GRM1552C1H560JD01D K22178230 1- B c1

C 1088 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B a2

C 1088 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- B a2

C 1089 CHIP CAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- B c1

C 1090 CHIP CAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- B c1

C 1091 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c1

C 1092 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b1

C 1092 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- B b1

C 1094 CHIP CAP. 68pF 50V CH GRM1552C1H680JZ01D K22178232 1- B c1

C 1095 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c1

C 1096 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c1

C 1097 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A D2

C 1098 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d1

C 1098 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- B d1

C 1099 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- B e1

C 1100 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d1

C 1100 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- B d1

C 1101 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d1

C 1102 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e1

C 1103 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d1

C 1104 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d1

C 1104 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- B d1

C 1105 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- B d1

C 1105 CHIP CAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 53- B d1

C 1107 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d1

C 1107 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- B d1

C 1108 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e1

C 1109 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e1

C 1110 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- B e3

C 1111 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- B e1

C 1111 CHIP CAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 53- B e1

C 1112 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e3

C 1113 CHIP TA.CAP. 1uF 16V TEESVA21C105M8R K78120024 1- A D2

C 1114 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e3

C 1115 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A E2

C 1116 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A D2

C 1118 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- B a2

C 1119 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B a2

C 1120 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a2

C 1126 CHIP CAP. 220pF 50V B GRM155B11H221KA01D K22178801 1- B c1

C 1127 CHIP CAP. 2.2uF 10V B ECJ2FB1A225K K22100807 1- B d2

C 1127 CHIP CAP. 2.2uF 10V B GRM21BB11A225KA01L K22100804 73- B d2

C 1129 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- A D1

C 1129 CHIP CAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 53- A D1

C 1131 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- B e1

C 1132 CHIP CAP. 270pF 25V CH GRM36CH271J25PT K22148248 1- B e1

C 1132 CHIP CAP. 270pF 50V CH GRM1552C1H271JA01D K22179715 53- B e1

C 1133 CHIP CAP. 10pF 50V CH GRM1552C1H100JZ01D K22178212 1- B e1

C 1134 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d1

C 1134 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- B d1
