PCB with Components (VX-424-2-5) CB3575003 CH:32, KEY and LCD Type

PCB with Components (VX-414-2-5) CB3575004 CH:32

PCB with Components (VX-424-2-5) CB3575017 CH:32,KEY and LCD Type,IS Type

PCB with Components (VX-414-2-5) CB3575018 CH:32,IS Type

Printed Circuit Board FR010400D 1-

Printed Circuit Board FR010400E 3-

Printed Circuit Board FR010400F 9-

Printed Circuit Board FR010400G 29-

Printed Circuit Board FR010400H 36-

Printed Circuit Board FR010400I 54-

C 1002 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a1

C 1006 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E1

C 1007 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A D1

C 1007 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- A D1

C 1008 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E1

C 1009 CHIP TA.CAP. 2.2uF 6.3V TEESVA0J225M8R K78080009 1- A D1

C 1009 CHIP TA.CAP. 2.2uF 6.3V TEESVP0J225M8R K78080051 36- A D1

C 1011 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E1

C 1013 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A C1

C 1015 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- A E3

C 1016 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A E2

C 1018 AL.ELECTRO.CAP. 220uF 10V EEE1AA221XP K48100007 1- B a2

C 1018 AL.ELECTRO.CAP. 220uF 10V UUR1A221MCL6GS K48100013 66- B a2

C 1019 CHIP CAP. 220pF 25V CH GRM36CH221J25PT K22148203 1- A E2

C 1019 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 53- A E2

C 1020 CHIP TA.CAP. 2.2uF 6.3V TEESVA0J225M8R K78080009 1- A E2

C 1020 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 34- A E2

C 1021 CHIP CAP. 10pF 50V CH GRM1552C1H100JZ01D K22178212 1- B a1

C 1024 CHIP CAP. 9pF 50V CH GRM1552C1H9R0DZ01D K22178211 1- B a1

C 1025 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B a1

C 1026 CHIP CAP. 6pF 50V CH GRM1552C1H6R0DZ01D K22178208 1- B a1

C 1027 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B a1

C 1028 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a1

C 1029 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 1- B a1

C 1031 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a1

C 1032 CHIP CAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B b1

C 1034 CHIP CAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B b1

C 1035 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E1

C 1036 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A E1

C 1037 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A E1

C 1037 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- A E1

C 1038 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b1

C 1041 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- A C1

C 1042 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- A C1

C 1043 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A C1

C 1044 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d1

C 1045 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- A C1

C 1046 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- B e1

C 1046 CHIP CAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 53- B e1

C 1047 CHIP CAP. 220pF 25V CH GRM36CH221J25PT K22148203 1- A D3

C 1047 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 53- A D3

C 1048 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- A D3

C 1050 CHIP CAP. 220pF 25V CH GRM36CH221J25PT K22148203 1- A D2

C 1050 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 53- A D2

C 1052 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A E2

C 1054 CHIP TA.CAP. 22uF 16V TEESVB21C226M8R K78120028 1- A E2

C 1055 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- A E2

C 1057 CHIP CAP. 22pF 50V CH GRM1552C1H220JZ01D K22178220 1- B a1

C 1058 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B a1

C 1059 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- B a1

C 1060 CHIP CAP. 47pF 50V CH GRM1552C1H470JZ01D K22178228 1- B a1

C 1062 CHIP TA.CAP. 4.7uF 16V TEESVB21C475M8R K78120016 IS VERSION 1- B b1

C 1062 CHIP TA.CAP. 10uF 16V TEESVB21C106M8R K78120025

NON IS VERSION

1- B b1

C 1063 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c1

C 1065 CHIP CAP. 22pF 50V CH GRM1552C1H220JZ01D K22178220 1- B b1

C 1066 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B b1

C 1068 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b1

Parts List

DESCRIPTION

VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.

REF.

LOT.

SIDE LAY ADR

MAIN Unit

Brand	Vertex Standard
Model	VX-420 Series
Category	Transceiver
Language	English

Vertex Standard VX-420 Series Service Manual
