DESCRIPTION

VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.

REF.

LOT.

SIDE LAY ADR

MAIN Unit

C 1135 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d1

C 1135 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- B d1

C 1136 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d1

C 1137 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e2

C 1138 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- B e1

C 1138 CHIP CAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 53- B e1

C 1139 CHIP CAP. 10pF 50V CH GRM1552C1H100JZ01D K22178212 1- B e1

C 1140 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- B e1

C 1140 CHIP CAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 53- B e1

C 1141 CHIP CAP. 22pF 50V CH GRM1552C1H220JZ01D K22178220 1- B d1

C 1143 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- B e1

C 1143 CHIP CAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 53- B e1

C 1144 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- A D2

C 1144 CHIP CAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 53- A D2

C 1145 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c1

C 1146 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A D2

C 1146 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- A D2

C 1147 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- B c2

C 1149 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a2

C 1150 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a2

C 1153 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B a2

C 1154 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- B a2

C 1156 CHIP CAP. 10pF 50V CH GRM1552C1H100JZ01D K22178212 1- B a2

C 1157 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- B c1

C 1158 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c1

C 1159 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 1- B c1

C 1160 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 1- B c1

C 1161 CHIP CAP. 220pF 25V CH GRM36CH221J25PT K22148203 1- B b2

C 1161 CHIP CAP. 220pF 50V CH GRM1552C1H221JA01D K22179713 53- B b2

C 1162 CHIP TA.CAP. 4.7uF 6.3V TEESVA0J475M8R K78080017 1- B b2

C 1163 CHIP TA.CAP. 4.7uF 16V TEESVA1C475M8R K78120031 1- B e2

C 1164 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e2

C 1165 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- B e1

C 1166 CHIP CAP. 1uF 6.3V B GRM188B10J105KA01D K22084801 1- B e1

C 1167 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e2

C 1168 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A D2

C 1169 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e3

C 1170 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e2

C 1171 CHIP CAP. 470pF 50V B GRM155B11H471KA01D K22178805 1- B e2

C 1172 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- B d1

C 1173 CHIP CAP. 22pF 50V CH GRM1552C1H220JZ01D K22178220 1- B e1

C 1174 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e1

C 1176 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e1

C 1177 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B a2

C 1180 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b2

C 1181 CHIP CAP. 9pF 50V CH GRM1552C1H9R0DZ01D K22178211 1- B b2

C 1182 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A D2

C 1183 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 1- B c1

C 1184 CHIP CAP. 18pF 50V CH GRM1552C1H180JZ01D K22178218 1- B c2

C 1186 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c2

C 1187 CHIP CAP. 2pF 50V CK GRM1554C1H2R0BZ01D K22178289 1- B c2

C 1188 CHIP CAP. 1pF 50V CK GRM1554C1H1R0BZ01D K22178287 1- B c2

C 1189 CHIP CAP. 10pF 50V CH GRM1552C1H100BZ01D K22178297 1- B c1

C 1190 CHIP TA.CAP. 4.7uF 6.3V TEESVP0J475M8R K78080053 1- B b2

C 1191 CHIP TA.CAP. 4.7uF 6.3V TEESVP0J475M8R K78080053 1- B b2

C 1192 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b2

C 1194 CHIP CAP. 1.5pF 50V CK GRM1554C1H1R5BZ01D K22178288 1- B c2

C 1195 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B e2

C 1196 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- B e2

C 1197 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e2

C 1198 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B e1

C 1198 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- B e1

C 1199 CHIP CAP. 7pF 50V CH GRM1552C1H7R0DZ01D K22178209 1- B b2

C 1200 CHIP CAP. 12pF 50V CH GRM1552C1H120JZ01D K22178214 1- B b2

C 1201 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b2

C 1201 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- B b2

C 1203 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b2
