DESCRIPTION

VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.

REF.

LOT.

SIDE

LAY ADR

MAIN Unit

C 1203 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- B b2

C 1204 CHIP CAP. 10pF 50V CH GRM1552C1H100BZ01D K22178297 1- B c2

C 1205 CHIP TA.CAP. 4.7uF 6.3V TEESVA0J475M8R K78080017 1- B b2

C 1207 CHIP CAP. 33pF 50V CH GRM1552C1H330JZ01D K22178224 1- B c2

C 1209 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c1

C 1211 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c2

C 1212 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b2

C 1213 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B c2

C 1214 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- B c2

C 1215 CHIP CAP. 150pF 50V CH GRM1552C1H151JA01D K22178240 1- B c2

C 1217 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 W/LCD 1- A C3

C 1218 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A D2

C 1219 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A D2

C 1220 CHIP CAP. 9pF 50V CH GRM1552C1H9R0DZ01D K22178211 1- A D2

C 1221 CHIP CAP. 15pF 50V CH GRM1552C1H150JZ01D K22178216 1- B c1

C 1223 CHIP CAP. 0.022uF 16V B GRM155B11C223KA01D K22128806 1- A D3

C 1224 CHIP CAP. 9pF 50V CH GRM1552C1H9R0DZ01D K22178211 1- B b2

C 1226 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B b3

C 1226 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- B b3

C 1227 CHIP TA.CAP. 0.047uF 35V TEESVA1V473M8R K78160023 1- B c2

C 1228 CHIP TA.CAP. 0.1uF 20V TEESVA21D104M8R K78130020 1- B d2

C 1229 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d1

C 1230 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d1

C 1230 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- B d1

C 1231 CHIP TA.CAP. 10uF 6.3V TEESVA0J106M8R K78080027 1- B d1

C 1232 CHIP TA.CAP. 1.5uF 16V TEESVA1C155M8R K78120020 1- B d2

C 1233 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d1

C 1234 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A E1

C 1235 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 W/LCD 1- A C3

C 1238 CHIP CAP. 9pF 50V CH GRM1552C1H9R0DZ01D K22178211 1- A D2

C 1239 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- A D2

C 1241 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- A D3

C 1242 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- A D3

C 1242 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- A D3

C 1243 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b3

C 1244 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B b2

C 1245 CHIP CAP. 0.047uF 10V B GRM155B11A473KA01D K22108801 1- B b2

C 1246 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c2

C 1248 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d2

C 1250 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B c2

C 1251 CHIP CAP. 82pF 50V CH GRM1552C1H820JD01D K22178234 1- B b2

C 1252 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c3

C 1254 CHIP CAP. 390pF 50V B GRM155B11H391KD01D K22178804 1- B d1

C 1256 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B d1

C 1257 CHIP CAP. 27pF 50V CH GRM1552C1H270JZ01D K22178222 1- B d2

C 1259 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d2

C 1259 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- B d2

C 1260 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B d2

C 1260 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- B d2

C 1261 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B d2

C 1262 CHIP CAP. 82pF 50V CH GRM1552C1H820JD01D K22178234 1- B c2

C 1263 CHIP CAP. 22pF 50V CH GRM1552C1H220JZ01D K22178220 1- B d2

C 1263 CHIP CAP. 39pF 50V CH GRM1552C1H390JZ01D K22178226 35- B d2

C 1264 CHIP CAP. 0.0047uF 25V B GRM36B472K25PT K22148830 1- B d2

C 1264 CHIP CAP. 0.0047uF 50V B GRM155B11H472KA01D K22178838 53- B d2

C 1265 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B d3

C 1266 CHIP CAP. 0.1uF 10V B GRM155B11A104KA01D K22108802 1- B c3

C 1267 CHIP CAP. 330pF 50V B GRM155B11H331KA01D K22178803 1- B c3

C 1267 CHIP CAP. 470pF 50V B GRM155B11H471KA01D K22178805 35- B c3

C 1268 CHIP CAP. 330pF 50V B GRM155B11H331KA01D K22178803 1- B c3

C 1268 CHIP CAP. 470pF 50V B GRM155B11H471KA01D K22178805 35- B c3

C 1269 CHIP CAP. 0.01uF 16V B GRM36B103K16PT K22128804 1- B c3

C 1269 CHIP CAP. 0.01uF 25V B GRM155B11E103KA01D K22148834 53- B c3

C 1270 CHIP CAP. 0.001uF 50V B GRM155B11H102KA01D K22178809 1- B e2

C 1271 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B c1

C 1272 CHIP CAP. 5pF 50V CH GRM1552C1H5R0CZ01D K22178207 1- B a1

C 1273 CHIP CAP. 100pF 50V CH GRM1552C1H101JD01D K22178236 1- B c1
