Vertex Standard VX-420 Series Service Manual

50
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE
LAY ADR
MAIN Unit
R 1006 CHIP RES. 680 1/16W 5% RMC1/16S 681JTH J24189023 1- A E2
R 1006 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 34- A E2
R 1007 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A D1
R 1008 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A D1
R 1009 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A D1
R 1010 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D1
R 1011 CHIP RES. 68 1/16W 5% RMC1/16 680JATP J24185680 1- B a1
R 1012 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A C1
R 1013 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A D1
R 1014 CHIP RES. 68 1/16W 5% RMC1/16 680JATP J24185680 1- B a1
R 1015 CHIP RES. 0.33 1/8W 10% RMC1/8 R33KTP J24219001 1- A E1
R 1016 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- A E1
R 1017 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A D1
R 1018 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- A E1
R 1020 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A E1
R 1021 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- A E1
R 1022 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d1
R 1023 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A C1
R 1024 CHIP RES. 8.2k 1/16W 5% RMC1/16S 822JTH J24189036 1- A C1
R 1025 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A D2
R 1026 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A C1
R 1027 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A D3
R 1028 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- A C1
R 1029 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- A C1
R 1030 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D1
R 1031 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d3
R 1032 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A E2
R 1033 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A E3
R 1034 CHIP RES. 220 1/16W 5% RMC1/16 221JATP J24185221 1- A E3
R 1035 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A D3
R 1035 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 34- A D3
R 1036 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A E3
R 1037 CHIP RES. 220 1/2W 5% RMC1/2 221JCTP J24275221 1- B b1
R 1038 CHIP RES. 0.33 1/8W 10% RMC1/8 R33KTP J24219001 1- A E1
R 1040 CHIP RES. 0.33 1/8W 10% RMC1/8 R33KTP J24219001 1- A E1
R 1041 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b1
R 1042 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B b1
R 1043 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- A D1
R 1044 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B d1
R 1044 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 48 B d1
R 1044 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 49- B d1
R 1045 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B e1
R 1046 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d2
R 1047 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- A D1
R 1048 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B d1
R 1048 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 48 B d1
R 1049 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d2
R 1050 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B d1
R 1051 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- B d3
R 1052 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B d3
R 1053 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B d3
R 1054 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B d3
R 1056 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- B d2
R 1057 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- B d1
R 1058 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- A C1
R 1059 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B e3
R 1060 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A C1
R 1061 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B e2
R 1062 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B e3
R 1063 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- B e3
R 1064 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B e3
R 1065 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a2
R 1066 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a2
R 1067 CHIP RES. 100 1/4W 5% RMC1/4 101JATP J24245101 1- B b1
R 1068 CHIP RES. 33 1/16W 5% RMC1/16S 330JTH J24189007 1- B c1
R 1069 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B c1
R 1070 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 1- B c1
