Vertex Standard VX-420 Series Service Manual

51
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR
MAIN Unit
R 1071 CHIP RES. 220k 1/16W 1% RMC1/16 224FTP J24183224 1- A D2
R 1072 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- B c1
R 1073 CHIP RES. 10k 1/16W 1% RMC1/16 103FTP J24183103 1- A D2
R 1074 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d1
R 1076 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A E2
R 1077 CHIP RES. 68k 1/16W 5% RMC1/16S 683JTH J24189047 1- B e1
R 1078 CHIP RES. 150k 1/16W 5% RMC1/16S 154JTH J24189051 1- B d1
R 1079 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B e1
R 1080 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- B d1
R 1081 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B e1
R 1082 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- B d1
R 1083 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B d1
R 1084 CHIP RES. 820k 1/16W 5% RMC1/16S 824JTH J24189060 1- B e1
R 1084 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 66- B e1
R 1085 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B e1
R 1086 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B e3
R 1087 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- A D2
R 1088 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- B e3
R 1089 CHIP RES. 560 1/16W 5% RMC1/16S 561JTH J24189022 1- A D2
R 1090 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B e3
R 1091 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B e3
R 1092 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B e3
R 1093 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B a2
R 1094 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a2
R 1095 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B d1
R 1096 CHIP RES. 100 1/16W 5% RMC1/16 101JATP J24185101 1- B b1
R 1097 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B a2
R 1098 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d2
R 1099 CHIP RES. 15 1/16W 5% RMC1/16S 150JTH J24189003 1- B c1
R 1100 CHIP RES. 27k 1/16W 5% RMC1/16S 273JTH J24189042 1- B c1
R 1101 CHIP RES. 10 1/16W 5% RMC1/16S 100JTH J24189001 1- B c1
R 1102 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d1
R 1104 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- B d1
R 1106 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d1
R 1107 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B e1
R 1108 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d1
R 1109 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B d1
R 1110 CHIP RES. 680k 1/16W 5% RMC1/16S 684JTH J24189059 1- B e1
R 1111 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e1
R 1112 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B d1
R 1113 CHIP RES. 330k 1/16W 5% RMC1/16S 334JTH J24189055 1- B e1
R 1114 CHIP RES. 120k 1/16W 5% RMC1/16S 124JTH J24189050 1- B e1
R 1115 CHIP RES. 120k 1/16W 5% RMC1/16S 124JTH J24189050 1- B e1
R 1116 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B e1
R 1117 CHIP RES. 270k 1/16W 5% RMC1/16S 274JTH J24189054 1- B e1
R 1118 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B e1
R 1118 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 34- B e1
R 1119 CHIP RES. 270k 1/16W 5% RMC1/16S 274JTH J24189054 1- B d1
R 1119 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 66- B d1
R 1120 CHIP RES. 12k 1/16W 5% RMC1/16S 123JTH J24189038 1- B e2
R 1121 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B e1
R 1122 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B e2
R 1123 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B e1
R 1124 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- A E2
R 1125 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D2
R 1126 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A E2
R 1127 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A E2
R 1128 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d1
R 1129 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B a2
R 1130 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a2
R 1131 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a2
R 1133 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B c1
R 1134 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B c2
R 1135 CHIP RES. 1.5k 1/16W 5% RMC1/16S 152JTH J24189027 1- B c2
R 1136 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e1
R 1137 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B c2
R 1138 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B b2
