Vertex Standard VX-420 Series Service Manual

52
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE
LAY ADR
MAIN Unit
R 1139 CHIP RES. 180k 1/16W 5% RMC1/16S 184JTH J24189052 1- B e1
R 1140 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B e1
R 1141 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B d2
R 1142 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B e1
R 1143 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B e1
R 1144 CHIP RES. 1M 1/16W 5% RMC1/16S 105JTH J24189061 1- B e1
R 1145 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B e2
R 1146 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B a3
R 1147 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B b2
R 1148 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b2
R 1149 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c2
R 1150 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B c2
R 1151 CHIP RES. 47 1/16W 5% RMC1/16S 470JTH J24189009 1- B c2
R 1152 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B c2
R 1153 CHIP RES. 100k 1/16W 5% RMC1/16S 104JTH J24189049 1- B c2
R 1154 CHIP RES. 33k 1/16W 5% RMC1/16S 333JTH J24189043 1- B c2
R 1155 CHIP RES. 680 1/16W 5% RMC1/16S 681JTH J24189023 1- B c2
R 1156 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b2
R 1157 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b2
R 1158 CHIP RES. 120 1/16W 5% RMC1/16S 121JTH J24189014 1- B b2
R 1158 CHIP RES. 220 1/16W 5% RMC1/16S 221JTH J24189017 67- B b2
R 1159 CHIP RES. 560 1/16W 5% RMC1/16S 561JTH J24189022 1- B b2
R 1160 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B b2
R 1161 CHIP RES. 10 1/16W 5% RMC1/16S 100JTH J24189001 1- B c2
R 1162 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B c2
R 1163 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B b1
R 1164 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B c2
R 1165 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 W/LCD 1- A C3
R 1166 CHIP RES. 180 1/16W 5% RMC1/16S 181JTH J24189016 W/LCD 1- B d3
R 1166 CHIP RES. 820 1/16W 5% RMC1/16S 821JTH J24189024 W/LCD 77- B d3
R 1167 CHIP RES. 180 1/16W 5% RMC1/16S 181JTH J24189016 W/LCD 1- B d3
R 1167 CHIP RES. 820 1/16W 5% RMC1/16S 821JTH J24189024 W/LCD 77- B d3
R 1168 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- A D3
R 1169 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B e2
R 1170 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- B e2
R 1171 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 1- A D2
R 1172 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e1
R 1173 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D3
R 1174 CHIP RES. 6.8k 1/16W 5% RMC1/16S 682JTH J24189035 1- A D3
R 1175 CHIP RES. 15k 1/16W 5% RMC1/16S 153JTH J24189039 1- A D3
R 1176 CHIP RES. 22 1/16W 5% RMC1/16S 220JTH J24189005 1- B b2
R 1177 CHIP RES. 390 1/16W 5% RMC1/16S 391JTH J24189020 1- B b2
R 1178 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B b3
R 1179 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B b3
R 1180 CHIP RES. 33 1/16W 5% RMC1/16S 330JTH J24189007 1- B b2
R 1181 CHIP RES. 33 1/16W 5% RMC1/16S 330JTH J24189007 1- B b2
R 1182 CHIP RES. 8.2k 1/16W 5% RMC1/16S 822JTH J24189036 1- B c2
R 1184 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B d2
R 1185 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B d2
R 1186 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d2
R 1188 CHIP RES. 33 1/16W 5% RMC1/16S 330JTH J24189007 1- B d1
R 1188 CHIP RES. 33 1/16W 5% RMC1/16S 330JTH J24189007 34- B d1
R 1189 CHIP RES. 33 1/16W 5% RMC1/16S 330JTH J24189007 1- B d1
R 1190 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A E1
R 1191 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 W/LCD 1- A C3
R 1192 CHIP RES. 330 1/16W 5% RMC1/16S 331JTH J24189019 1- A E1
R 1193 CHIP RES. 150 1/16W 5% RMC1/16S 151JTH J24189015 1- A E1
R 1194 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A D3
R 1195 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D2
R 1196 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 1197 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 W/LCD 1- A C3
R 1198 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 1199 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B e1
R 1200 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 1201 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 1202 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A D2
R 1203 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
