Vertex Standard VX-420 Series Service Manual

53
MAIN Unit
DESCRIPTION
VALUE V/W TOL. VXSTD P/NMFR’S DESIG VERS.
REF.
LOT.
SIDE LAY ADR
R 1204 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 1205 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 1206 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 1207 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 1208 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 1209 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 1210 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 1211 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 1212 CHIP RES. 470 1/16W 5% RMC1/16S 471JTH J24189021 1- A C3
R 1214 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 1215 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 1216 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 1217 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D2
R 1218 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D1
R 1219 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D1
R 1220 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D1
R 1221 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D1
R 1222 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D1
R 1223 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D1
R 1224 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D1
R 1225 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- A D3
R 1226 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C1
R 1227 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- A D1
R 1228 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C1
R 1230 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- B c2
R 1231 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d2
R 1232 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d1
R 1234 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B d2
R 1235 CHIP RES. 100 1/16W 5% RMC1/16S 101JTH J24189013 1- B d2
R 1236 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d2
R 1237 CHIP RES. 47k 1/16W 5% RMC1/16S 473JTH J24189045 1- B d2
R 1238 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C2
R 1239 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C2
R 1240 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C3
R 1241 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C3
R 1242 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C3
R 1243 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C3
R 1244 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C3
R 1245 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C3
R 1246 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C3
R 1247 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C2
R 1248 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A D1
R 1249 CHIP RES. 10k 1/16W 5% RMC1/16S 103JTH J24189037 1- A C1
R 1250 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C1
R 1251 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C1
R 1252 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C1
R 1253 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C1
R 1254 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C1
R 1255 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 1- A C1
R 1256 CHIP RES. 82k 1/16W 5% RMC1/16S 823JTH J24189048 1- A C1
R 1257 CHIP RES. 39k 1/16W 5% RMC1/16S 393JTH J24189044 1- A C1
R 1258 CHIP RES. 22k 1/16W 5% RMC1/16S 223JTH J24189041 1- A C1
R 1259 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 1- B c2
R 1259 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 66- B c2
R 1260 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B d2
R 1260 CHIP RES. 2.7k 1/16W 5% RMC1/16S 272JTH J24189030 66- B d2
R 1261 CHIP RES. 4.7k 1/16W 5% RMC1/16S 472JTH J24189033 1- B d2
R 1262 CHIP RES. 5.6k 1/16W 5% RMC1/16S 562JTH J24189034 1- B d3
R 1263 CHIP RES. 220k 1/16W 5% RMC1/16S 224JTH J24189053 1- B c2
R 1263 CHIP RES. 470k 1/16W 5% RMC1/16S 474JTH J24189057 35- B c2
R 1264 CHIP RES. 680k 1/16W 5% RMC1/16S 684JTH J24189059 1- B d2
R 1264 CHIP RES. 820k 1/16W 5% RMC1/16S 824JTH J24189060 35- B d2
R 1265 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B c3
R 1265 CHIP RES. 1k 1/16W 5% RMC1/16S 102JTH J24189025 35- B c3
R 1266 CHIP RES. 0 1/16W 5% RMC1/16S JPTH J24189070 1- B d3
R 1267 CHIP RES. 3.3k 1/16W 5% RMC1/16S 332JTH J24189031 1- B c3
R 1268 CHIP RES. 2.2k 1/16W 5% RMC1/16S 222JTH J24189029 1- B e2
