Vertex Standard VXR-9000 Service Manual

O-8
100W PA Unit (Option: Version D)
Parts List
VXR-9000 UHF Service Manual
R 6075 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A A3
R 6077 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A L7
R 6078 CHIP RES. 15k 1/10W 5% RMC1/10T 153J J24205153 1- A M8
R 6079 CHIP RES. 15k 1/10W 5% RMC1/10T 153J J24205153 1- A M8
R 6080 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A L7
R 6082 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A I2
R 6083 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A I2
R 6084 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B2
R 6085 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B2
R 6086 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A B2
R 6087 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A B2
R 6088 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B2
R 6089 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B2
R 6090 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A A3
R 6091 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- A B3
R 6092 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A A2
R 6093 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A B3
R 6095 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B3
R 6096 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B3
R 6097 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B3
R 6098 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A3
R 6099 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A3
R 6100 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A3
R 6101 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B3
R 6102 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A3
R 6103 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A3
R 6104 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A3
R 6105 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B3
R 6106 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B2
R 6107 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B3
R 6108 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B3
R 6109 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B3
R 6110 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B2
R 6111 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B2
R 6112 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B3
R 6113 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B3
R 6115 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A J6
R 6116 CHIP RES. 22k 1/16W 5% RMC1/16 223JATP J24185223 1- A A3
R 6118 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- A E4
R 6119 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- A E7
R 6120 CHIP RES. 150 1/10W 5% RMC1/10T 151J J24205151 1- A L6
R 6121 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A L7
R 6122 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A3
R 6123 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A3
R 6124 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A3
R 6125 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A3
R 6126 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A3
R 6127 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A3
R 6128 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A3
R 6129 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A A3
R 6130 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A L3
R 6131 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A L6
R 6132 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A L7
R 6133 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A L8
R 6134 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A B3
R 6135 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A L2
R 6136 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A L2
R 6137 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A J6
R 6138 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- A K5
TH6001 THERMISTOR 157-203-55009TP G9090045 1- A G2
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
