H-13

MAIN Unit

Parts List

VXR-9000 UHF Service Manual

PCB with Components CS2132704 DST: USA VER. D

CS2132705 DST: EXP VER. D

CS2132706 DST: AUS VER. D

CS2132707 DST: USA VER. A

CS2132708 DST: EXP VER. A

C 1001 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A G4

C 1002 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B d1

C 1003 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A G5

C 1004 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B d1

C 1005 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A G4

C 1007 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B d1

C 1008 CHIP TA.CAP. 47uF 4V SK7-0G476M-RA K78060048 1- B d3

C 1009 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A D3

C 1010 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B d1

C 1011 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B e3

C 1012 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 1- A G4

C 1014 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A F4

C 1015 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 1-20 A F5

C 1015 CHIP CAP. 8pF 50V CH GRM1882C1H8R0CZ01D K22174246 VER. A 21- A F5

C 1015 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 VER. D 21- A F5

C 1016 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- B d4

C 1017 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 1- A F4

C 1018 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A F4

C 1019 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B d4

C 1021 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 1- A F4

C 1022 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B d1

C 1023 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B a5

C 1024 CHIP CAP. 27pF 50V CH GRM1882C1H270JA01D K22174221 1- A C3

C 1025 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A F5

C 1027 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3

C 1028 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B f3

C 1029 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B d1

C 1032 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A F4

C 1034 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B b5

C 1035 AL.ELECTRO.CAP. 100uF 16V EEE1CA101WP K48120012 1- A D4

C 1036 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A D3

C 1037 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B d3

C 1040 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A F4

C 1043 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B d3

C 1044 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 1-20 A F5

C 1044 CHIP CAP. 8pF 50V CH GRM1882C1H8R0CZ01D K22174246 VER. A 21- A F5

C 1044 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 VER. D 21- A F5

C 1045 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 1- A F4

C 1046 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C3

C 1047 AL.ELECTRO.CAP. 22uF 16V ECEV1CA220SR K48120002 1-25 A D3

C 1047 AL.ELECTRO.CAP. 22uF 16V EEE1CA220SR K48120024 26- A D3

C 1048 CHIP CAP. 0.022uF 25V B GRM39B223K25PT K22144807 1-47 A D4

C 1048 CHIP CAP. 0.022uF 50V B GRM188B11H223KA01D K22174839 48- A D4

C 1050 CHIP CAP. 0.0015uF 50V B GRM188B11H152KA01D K22174827 1- A D4

C 1051 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C4

C 1052 CHIP TA.CAP. 47uF 4V SK7-0G476M-RA K78060048 1- B d3

C 1053 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- A C2

C 1054 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B d3

C 1055 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C2

C 1056 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E4

C 1057 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C4

C 1058 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B e4

C 1059 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- A C2

C 1060 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 1- A F5

C 1061 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A F5

C 1062 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 1- A C2

C 1065 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 1- A E4

C 1066 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- B e4

C 1067 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 1- A F4

C 1068 CHIP TA.CAP. 22uF 6.3V TEESVA0J226M8R K78080047 1- B d3

C 1070 CHIP CAP. 220pF 50V CH GRM1882C1H221JA01D K22174243 1- A C2

C 1071 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 1- A E4

C 1073 CHIP TA.CAP. 47uF 6.3V TEESVB20J476M8R K78080048 1- B d4

C 1074 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A E4

C 1075 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 1-20 A E5

C 1075 CHIP CAP. 8pF 50V CH GRM1882C1H8R0CZ01D K22174246 VER. A 21- A E5

C 1075 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 VER. D 21- A E5

C 1076 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e2

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE

LAY ADR
