H-14

MAIN Unit

Parts List

VXR-9000 UHF Service Manual

C 1077 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A C2

C 1079 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A E4

C 1080 CHIP CAP. 0.0056uF 50V B GRM188B11H562KA01D K22174818 1- B e4

C 1081 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B c5

C 1082 CHIP CAP. 12pF 50V CH GRM1882C1H120JA01D K22174213 1- A E4

C 1083 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B e2

C 1084 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B c5

C 1085 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B c5

C 1086 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 1- A E4

C 1090 CHIP CAP. 330pF 50V CH GRM1882C1H331JA01D K22174253 1- A C5

C 1092 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A E4

C 1093 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- B e2

C 1094 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A E4

C 1095 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 1-20 A E5

C 1095 CHIP CAP. 8pF 50V CH GRM1882C1H8R0CZ01D K22174246 VER. A 21- A E5

C 1095 CHIP CAP. 7pF 50V CH GRM1882C1H7R0DZ01D K22174208 VER. D 21- A E5

C 1096 CHIP TA.CAP. 33uF 10V TEESVB21A336M8R K78100047 1- B e4

C 1097 CHIP CAP. 6pF 50V CH GRM1882C1H6R0DZ01D K22174207 1- A E4

C 1099 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A E4

C 1101 AL.ELECTRO.CAP. 100uF 16V EEE1CA101WP K48120012 1- A D2

C 1102 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B d2

C 1103 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B d2

C 1104 CHIP CAP. 47pF 50V CH GRM1882C1H470JA01D K22174227 1- A C4

C 1105 CHIP TA.CAP. 22uF 16V TEESVB21C226M8R K78120028 1- B d2

C 1107 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A E4

C 1108 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B d2

C 1109 AL.ELECTRO.CAP. 100uF 16V EEE1CA101WP K48120012 1- A C4

C 1110 CHIP CAP. 1uF 10V F GRM188F11A105ZA01D K22105001 1- B e5

C 1111 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A E5

C 1112 CHIP CAP. 0.01uF 50V B GRM188B11H103KA01D K22174823 1- B d2

C 1115 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A D4

C 1117 CHIP TA.CAP. 47uF 4V SK7-0G476M-RA K78060048 1- B e4

C 1118 CHIP TA.CAP. 1.5uF 16V TEESVA1C155M8R K78120020 1- A D1

C 1119 CHIP CAP. 3pF 50V CJ GRM1883C1H3R0CZ01D K22174204 1- A D4

C 1120 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A D1

C 1121 CHIP CAP. 4pF 50V CH GRM1882C1H4R0CZ01D K22174205 1- A E4

C 1122 CHIP CAP. 56pF 50V CH GRM1882C1H560JA01D K22174229 1- B e4

C 1123 CHIP CAP. 0.5pF 50V CK GRM1884C1HR50CZ01D K22174201 1- A E4

C 1124 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E2

C 1125 CHIP TA.CAP. 0.1uF 35V TEESVA1V104M8R K78160025 1- A D1

C 1126 CHIP CAP. 270pF 50V CH GRM1882C1H271JA01D K22174251 1- A C4

C 1127 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- A D4

C 1128 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 1- A D2

C 1130 CHIP CAP. 680pF 25V CH GRM39CH681J25PT K22144203 1-47 A C4

C 1130 CHIP CAP. 680pF 50V CH GRM1882C1H681JA01D K22174274 48- A C4

C 1131 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- B c3

C 1132 CHIP TA.CAP. 10uF 10V TEESVA1A106M8R K78100028 1- B d4

C 1134 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 1- A D2

C 1135 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 1- B c3

C 1136 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B e1

C 1138 CHIP TA.CAP. 1uF 25V TEESVA1E105M8R K78140013 1- B e4

C 1139 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 1- B c2

C 1140 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E3

C 1141 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- A E3

C 1142 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B e4

C 1143 CHIP CAP. 120pF 50V CH GRM1882C1H121JA01D K22174237 1- A C3

C 1144 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B c2

C 1146 CHIP CAP. 0.0022uF 50V B GRM188B11H222KA01D K22174822 1- A C3

C 1148 CHIP CAP. 100pF 50V CH GRM1882C1H101JA01D K22174235 1- B b2

C 1149 CHIP CAP. 8pF 50V CH GRM1882C1H8R0DZ01D K22174209 1- A E2

C 1150 CHIP CAP. 0.1uF 16V B GRM188B11C104KA01D K22124805 1- A B3

C 1151 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 1-20 A C1

C 1151 CHIP CAP. 9pF 50V CH GRM1882C1H9R0DZ01D K22174210 VER. A 21-22 A C1

C 1151 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 VER. A 23- A C1

C 1151 CHIP CAP. 15pF 50V CH GRM1882C1H150JA01D K22174215 VER. D 21-24 A C1

C 1151 CHIP CAP. 12pF 50V CH GRM1882C1H120JA01D K22174213 VER. D 25-38 A C1

C 1151 CHIP CAP. 10pF 50V CH GRM1882C1H100JA01D K22174211 VER. D 39-56 A C1

C 1151 CHIP CAP. 11pF 50V CH GRM1882C1H110JZ01D K22174212 VER. D 57- A C1

C 1153 CHIP CAP. 0.001uF 50V B GRM188B11H102KA01D K22174821 1- B b2

C 1154 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 1-20 A C1

C 1154 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 VER. A 21-22 A C1

C 1154 CHIP CAP. 2pF 50V CK GRM1884C1H2R0CZ01D K22174203 VER. A 23- A C1

C 1154 CHIP CAP. 1pF 50V CK GRM1884C1H1R0CZ01D K22174202 VER. D 21-22 A C1

REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE
