Vertex Standard VXR-9000 Service Manual

J-7
PANEL Unit
Parts List
VXR-9000 UHF Service Manual
QS4001 IC SOCKET DIP624G11S1-F P3090112 17- A E1
R 4001 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B c3
R 4002 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B c3
R 4003 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B c3
R 4004 CHIP RES. 220k 1/16W 5% RMC1/16 224JATP J24185224 1- B d3
R 4005 CHIP RES. 56k 1/16W 5% RMC1/16 563JATP J24185563 1- B d3
R 4006 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B c3
R 4007 CHIP RES. 12k 1/16W 5% RMC1/16 123JATP J24185123 1- B e3
R 4008 CHIP RES. 100k 1/16W 5% RMC1/16 104JATP J24185104 1- B e3
R 4009 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B c3
R 4010 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B c3
R 4011 CHIP RES. 82k 1/16W 5% RMC1/16 823JATP J24185823 1- B e3
R 4012 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B e3
R 4013 CHIP RES. 2.7k 1/16W 5% RMC1/16 272JATP J24185272 1- B e3
R 4014 CHIP RES. 3.3k 1/16W 5% RMC1/16 332JATP J24185332 1- B e3
R 4015 CHIP RES. 27k 1/16W 5% RMC1/16 273JATP J24185273 1-45 B e3
R 4015 CHIP RES. 27k 1/16W 5% RMC1/16 273JATP J24185273 AUS 46- B e3
R 4015 CHIP RES. 27k 1/16W 5% RMC1/16 273JATP J24185273 EXP 46- B e3
R 4015 CHIP RES. 27k 1/16W 5% RMC1/16 273JATP J24185273 USA 46- B e3
R 4016 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- B c1
R 4018 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- B c1
R 4019 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- B c2
R 4020 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- B c2
R 4021 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- B a1
R 4022 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- B c2
R 4023 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- B a1
R 4024 CHIP RES. 560k 1/16W 5% RMC1/16 564JATP J24185564 1- B e3
R 4025 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- B c2
R 4026 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- A F2
R 4027 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- B c1
R 4028 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- B c1
R 4029 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- A F2
R 4030 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B e3
R 4031 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- A F2
R 4032 CHIP RES. 56k 1/16W 5% RMC1/16 563JATP J24185563 1- B e3
R 4033 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- B a1
R 4035 CHIP RES. 560 1/4W 5% RMC1/4 561JATP J24245561 1-79 B e2
R 4035 CHIP RES. 680 1/4W 5% RMC1/4 681JATP J24245681 80- B e2
R 4036 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B e3
R 4037 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- A F2
R 4039 CHIP RES. 330 1/10W 5% RMC1/10T 331J J24205331 1- B a1
R 4040 CHIP RES. 0 1/16W 5% RMC1/16 000JATP J24185000 1- B e3
R 4041 CHIP RES. 560 1/16W 5% RMC1/16 561JATP J24185561 1- B e3
R 4042 CHIP RES. 560 1/4W 5% RMC1/4 561JATP J24245561 1- B e2
R 4043 CHIP RES. 2.2k 1/16W 5% RMC1/16 222JATP J24185222 1- A A3
R 4044 CHIP RES. 560 1/4W 5% RMC1/4 561JATP J24245561 1- B a3
R 4045 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B e1
R 4046 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B d1
R 4047 CHIP RES. 560 1/4W 5% RMC1/4 561JATP J24245561 1-68 B a3
R 4047 CHIP RES. 680 1/4W 5% RMC1/4 681JATP J24245681 69- B a3
R 4048 CHIP RES. 560 1/4W 5% RMC1/4 561JATP J24245561 1- B d1
R 4049 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B e1
R 4050 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B d2
R 4051 CHIP RES. 560 1/4W 5% RMC1/4 561JATP J24245561 1- B d1
R 4052 CHIP RES. 560 1/4W 5% RMC1/4 561JATP J24245561 1- B e2
R 4053 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B a3
R 4054 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B a3
R 4055 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B a3
R 4056 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B d2
R 4057 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B d2
R 4058 CHIP RES. 560 1/4W 5% RMC1/4 561JATP J24245561 1- B d2
R 4059 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B a2
R 4060 CHIP RES. 47k 1/16W 5% RMC1/16 473JATP J24185473 1- B d1
R 4061 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B d2
R 4062 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A A3
R 4063 CHIP RES. 560 1/4W 5% RMC1/4 561JATP J24245561 1- B e2
R 4064 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B d2
R 4065 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A A3
R 4066 CHIP RES. 10k 1/16W 5% RMC1/16 103JATP J24185103 1- B d2
R 4067 CHIP RES. 560 1/4W 5% RMC1/4 561JATP J24245561 1- B d2
R 4068 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B d2
R 4069 CHIP RES. 1k 1/16W 5% RMC1/16 102JATP J24185102 1- A A3
R 4070 CHIP RES. 330 1/16W 5% RMC1/16 331JATP J24185331 1- B c1
REF DESCRIPTION VALUE V/W TOL. MFR'S DESIG VXSTD P/N VERS. LOT SIDE LAY ADR
